0.5KV

1KV

1.5KV

2KV

3KV

4KV

5KV

7.5KV

10KV

2W

2.5W

3W

4W

5W

6W

8W

10W

1. Models from1kV to 30kV,  10W MAX

2. Low output ripple and noise ＜ 2mV P-P

3. High stability 0.001% per hour

4. Low temperature coefficient 0.001%/℃

5. Arc and Short Circuit Protected

6. External potentiometer or external control voltage to set.

7. Optional RS-232, RS-485 control, address can be set and search

8. Positive or negative output

9. Small size, Low noise, 6 -sided metal shielding

10. OEM customization available

11.CE certification

1KV

2KV

2.5KV

3KV

5KV

10KV

15KV

20KV

30KV

5W

10W

20W

1. Models from1kV to 30kV,  5W, 10W, 20W

2. Low output ripple and noise ＜0.001% P-P

3. High stability 25ppm per hour

4. Low temperature coefficient 25ppm/℃

5. Arc and Short Circuit Protected

6. External potentiometer or external control voltage to set.

7. Optional RS-232, RS-485 control, address can be set and research

8. Positive or negative output

9. Small size, Low noise , six -sided metal shielding

10. OEM customization available

1KV

2KV

2.5KV

3KV

5KV

10KV

15KV

20KV

30KV

5W

10W

20W

1. Ideal for SEM and MASS

2. Models from1kV to 30kV,  5W, 10W, 20W

3. Low output ripple and noise less than 3mV P-P

4. High stability 10ppm/hour,20ppm/8hour,100ppm/1000hour

5. Low temperature coefficient 10ppm/℃

6. Arc and Short Circuit Protected

7. External potentiometer or external control voltage to set.

8. Optional RS-232, RS-485 control, address can be set and research

9. Positive or negative output

10. Small size, Low noise,6 -sided metal shielding

11. OEM customized available.

1KV

2KV

2.5KV

3KV

5KV

10KV

15KV

20KV

30KV

5W

10W

20W

1. Ideal for SEM and Mass spectrometry

2. Models from1kV to 30kV,  5W, 10W, 20W

3. Low output ripple and noise less than 3mV P-P

4. High stability 10ppm/hour,20ppm/8hour,100ppm/1000hour

5. Low temperature coefficient 10ppm/℃

6. Arc and Short Circuit Protected

7. External potentiometer or external control voltage to set.

8. Ethernet,RS-232 Standard，RS-485 optionl, address can be set and research

9. Positive or negative output

10. Small size, Low noise,6 -sided metal shielding

11. OEM customized available.

0.3KV

0.6KV

1KV

1.5KV

3KV

6KV

10KV

15KV

20KV

25KV

30KV

5W

10W

20W

30W

60W

1. Models from0.3kV to 30kV,  5W to 60W

2. Low output ripple and noise less than 0.001% P-P

3. High stability 0.01% every 8 hours

4. Low temperature coefficient 0.0025%/℃

5. Arc and Short Circuit Protected

6. External potentiometer or external control voltage to set.

7. Positive or negative output

8. Small size, Low noise , 6 -sided metal shielding

9. OEM customization available

20KV

30KV

10W

15W

1.DNA sequencer，Electrophoresis

2.Models from20kV to 30kV, 10W,15W

3. Low output ripple and noise ≤ 0.01% P-P

4. High stability 0.01%/8 hours

5. Low temperature coefficient 25ppm/ ℃

6. Arc and Short Circuit Protected

7. External potentiometer or external control voltage to set.

8. Positive or negative output

9. Small size, Low noise , 6 -sided metal shielding

10. OEM customization available

0.6KV

1.2KV

2KV

3KV

5KV

7.5KV

10KV

12KV

15KV

20KV

25KV

30KV

6W

9W

15W

30W

60W

75W

100W

1. Models from3kV to 30kV, 6W to 100W

2. Low output ripple and noise less than 0.1% P-P

3. High stability 0.01% /8 hours

4. Low temperature coefficient 25PPM/ ℃

5. Arc and Short Circuit Protected

6. External potentiometer or external control voltage to set.

7. Optional RS-232, RS-485 control, address can be set and research

8. Positive or negative output

9. Small size, Low noise , 6 -sided metal shielding

10. OEM customization available

1KV

1.2KV

2KV

3KV

5KV

7.5KV

10KV

12KV

15KV

20KV

25KV

30KV

6W

9W

15W

30W

60W

75W

100W

1. Models from 3kV to 30kV, 6W to 100W

2. Option usb2.0,RS-232 or RS-422 serial interface

3. Low temperature coefficient 25ppm/ ℃

4. Low output ripple and noise 0.001% p-p

5. High stability 0.01% per hour

6. Local and remote voltage programming

7. Positive or negative polarity

8. Arc and short circuit protection

9. Safety interlock circuit

10. Compact size

11. OEM customization available

1KV

3KV

6KV

10KV

20KV

30KV

40KV

50KV

10W

30W

50W

1. Models from1kV to 50kV, 10W,30W,50W

2. Low output ripple and noise ＜ 0.1% P-P

3. High stability 0.02%/8 hours

4. Low temperature coefficient 0.0025%/ ℃

5. Arc and Short Circuit Protected

6. External potentiometer or external control voltage to set.

7. Optional RS-232,  Ethernet interface,  RS-485

8. Positive or negative output

9. Small size, Low noise , 6 -sided metal shielding

10. OEM customization available

40KV

50KV

60KV

65KV

70KV

10W

30W

50W

65W

75W

100W

1. Models from 40kV to 70kV, 10W to 100W

2. Low output ripple and noise ≤ 0.1% P-P

3. High stability 0.02%/8 hours

4. Low temperature coefficient 0.0025%/ ℃

5. Arc and Short Circuit Protected

6. External potentiometer or external control voltage to set.

7. Optional USB2.0, RS-232, RS-422 control,

8. Positive or negative output

9. Small size,  Low noise , 6 -sided metal shielding

10. OEM customization available

1KV

3KV

6KV

10KV

20KV

30KV

40KV

50KV

60KV

65KV

10W

30W

50W

65W

75W

100W

1. Output from 1kv to 65kv,10w to 100w

2. Option usb2.0,rs-232 or rs-422 serial interface

3. Low temperature coefficient 25ppm/ ℃

4. Low output ripple and noise 0.1% p-p

5. High stability 0.01% per hour

6. Local and remote voltage to set

7. Positive or negative polarity

8. Arc and short circuit Protected

9. Safety interlock circuit

10. Compact size

11. OEM customization available

1KV

3KV

5KV

10KV

15KV

20KV

30KV

40KV

50KV

60KV

70KV

120W

1. Power factor corrected  input 86Vac~265Vac

2. Models from 1kV to 70kV,  120W

3. Low output ripple and noise ≤ 0.1% P-P

4. High stability 0.02% every 8 hours

5. Low temperature coefficient 0.0025%/ ℃

6. Arc and short circuit Protected

7. External potentiometer or external control voltage to set.

8. Optional USB2.0, RS-232, RS-422 control,

9. Positive or negative output

10. OEM customization available

1KV

3KV

5KV

10KV

15KV

20KV

30KV

40KV

50KV

60KV

70KV

80KV

90KV

100KV

75W

90W

100W

120W

150W

200W

1. Models from 1kV to 100kV,75W to 200W

2. Low output ripple and noise ≤ 0.1% P-P

3. High stability 0.02% / 8 hours

4. Low temperature coefficient 0.0025% / ℃

5. Arc and short circuit Protected

6. External potentiometer or external control voltage to set.

7. Optional USB2.0, RS-232, RS-485 control,

8. Positive or negative output

9. Small size,Low noise , 6 -sided metal shielding

10. OEM customization available

1KV

5KV

10KV

20KV

30KV

40KV

60KV

70KV

80KV

100KV

120KV

140KV

100W

150W

200W

280W

1. Models from ±10KV to ±70KV,100w to 280w

2. Overvoltage, Arc and short circuit Protected

3. Automatic constant voltage and current

4. High stability, low ripple

5. Local or remote control

6. Safe interlock function is optional

7. RS-232, RS422 computer control

8. OEM customized available

9. 2 channels, one positive and one negative，two positive or two negative.

1KV

3KV

5KV

10KV

15KV

20KV

25KV

30KV

40KV

50KV

60KV

70KV

200W

350W

1. Power factor corrected  input 86Vac~265Vac

2. Models from1KV to 70KV, 200W,350W

3. Size 80mm x 254mm x280mm

4. Overvoltage, Arc and short circuit Protected

5. Voltage and current adjustment function

6. Local or remote  control

7. Safety interlock function

8. OEM customization available

9. Optional Ethernet, RS-232, RS-485 Interfaces

10. High stability can be customized

1KV

3KV

5KV

10KV

15KV

20KV

30KV

35KV

40KV

50KV

60KV

70KV

300W

600W

1200W

1. Power factor corrected  input 86Vac~265Vac

2. Models from1KV to 70KV, 300W,600W,1200W

3. Low output ripple and noise ≤ 0.1% P-P

4. High stability 0.02% every 8 hours

5. Low temperature coefficient 0.0025% / ℃

6. Spark protection and short circuit protection

7. External potentiometer or external control voltage to set.

8. Optional USB2.0, RS-232, RS-422 Interfaces,

9. Positive or negative output

10. OEM customization available

1KV

2KV

3KV

6KV

8KV

10KV

15KV

20KV

6W

9W

15W

30W

60W

75W

100W

1. Output from 0.6kv to 20kv @ 6w to 100w

2. Compact size, high power

3. Iow temperature coefficient 25ppm/℃

4. Low output ripple and noise 0.1% p-p

5. High stability 0.01% per 8 hour

6. Local and remote voltage programming

7. Positive or negative output

8. Arc and short circuit protection

9. OEM customization available

8KV

10KV

12KV

15KV

20KV

25KV

30KV

40KV

50KV

60KV

300W

1. Input 105Vac-125Vac or 210Vac-250Vac

2. Output voltage up to 60KV, output power 300W

3. Low output ripple and noise less than 0.05% P-P

4. High stability 0.01% per hour

5. Low temperature coefficient 25ppm per degree Celsius

6. Air insulation, fast dynamic response

7. Extremely low arc discharge current, strong ignition protection and short circuit protection

8. External potentiometer or external control voltage given

9. Suitable for harsh and harsh loads

10. Positive or negative polarity output

11. OEM customization

1KV

60KV

10W

75W

Wisman MEB series high voltage power supply has excellent regulation performance, this power output in 1kV60kV optional, MEB series uses air insulation under the premise of ensuring safety and stability, greatly reducing the weight of MEB series to make it more convenient and practical, is a low noise ,high efficiency constant voltage and current power supply.

3KV

5KV

10KV

15KV

20KV

30KV

15W

1. Input voltage 105Vac~125Vac or 210Vac~250Vac.

2. Output voltage 30kVmax, output power 15W.

3. Low output ripple and noise≤ 0.05%p-p.

4. High stability 0.01% per hour.

5. Low temperature coefficient 25ppm/℃.

6. Strong arc protection and short circuit protection.

7. External potentionmeter or external control voltage to set.

8. Air insulation, the mimum storage is 200mJ.

9. Postive or Negative output.
